2MBI50F-060 Product details
Features
● Low Saturation Voltage
● Voltage Drive
● Variety of Power Capacity Series
Applications
● Inverter for Motor Drive
● AC and DC Servo Drive Amplifier
● Uninterruptible Power Supply
● Industrial Machines, such as Welding Machines
Maximum ratings and characteristics
.Absolute maximum ratings (Tc=25°C unless without specified)
Collector-Emitter voltage Vces:600V
Gate-Emitter voltage VGES:±20V
Collector current Ic Continuous Tc=25°C :50A
Collector current Icp 1ms Tc=25°C :100A
Collector power dissipation Pc:220W
Isolation Voltage VIsol (AC 1 minute) :2500V
Operating junction temperature Tj:+150°C
Storage temperature Tstg :-40 to +125°C
Mounting screw torque 3.5 *1 N·m
Weight Typical value 185g
