Microsemi Power Products Group APTGT100TL60T3G IGBT Module

Manufacturer Part Number: APTGT100TL60T3GRohs Code: YesPart Life Cycle Code: ActiveIhs Manufacturer: MICROSEMI CORPPackage Description: FLANGE MOUNT, R-XUFM-X16Pin Count: 25ECCN Code: EAR99Manufacturer: Microsemi CorporationRisk Rank: 5.68Case Connection: ISOLATEDCollector Current-Max (IC): 150 ACollector-Emitter Voltage-Max: 600 VConfiguration: COMPLEXGate-Emitter Voltage-Max: 20 VJESD-30 Code: R-XUFM-X16Number of Elements: 4Number of Terminals: 16Operating Temperature-Max: 175 °CPackage Body Material: UNSPECIFIEDPackage Shape: RECTANGULARPackage Style: FLANGE MOUNTPeak Reflow Temperature (Cel): NOT SPECIFIEDPolarity/Channel Type: N-CHANNELPower Dissipation-Max (Abs): 340 WQualification Status: Not QualifiedSubcategory: Insulated Gate BIP TransistorsSurface Mount: NOTerminal Form: UNSPECIFIEDTerminal Position: UPPERTime Insulated Gate Bipolar Transistor, 150A I(C), 600V V(BR)CES, N-Channel, ROHS COMPLIANT, SP3, 25 PIN
