CPT CLAA150XP07Q LCD Display

Manufacturer CPT Model Name CLAA150XP07Q   Screen Size 15.0 inch Screen Type LCM,   a-Si TFT-LCD Pixel Number 1024(RGB)×768   (XGA)  85PPI Arrangement RGB Vertical Stripe Active Area(mm) 304.128 × 228.096 (H×V) Outline(mm) 326.5 × 253.5 × 14.5 (H×V×D) Bezel Area(mm) 307.4 × 231.3 (H×V) Treatment Antiglare Luminance 350 cd/m² (Typ.) Contrast Ratio 500 : 1 (Min.) (TM)     Viewing Angle 70/70/60/65 (Typ.)(CR≥10) Left / Right / Up / Down Response8 (Typ.)(Tr+Td) ms Good View at 6 o'clock Work Mode TN, Normally White, Transmissive Color Depth 16.2M   65% NTSC Backlight 4 pcs CCFL , 50K hours , No Driver Mass 1.30Kgs (Typ.) Used for Desktop Monitor Refresh Rate 60Hz  120Hz (60HZ Input) : Embedded MEMC Circuit 120Hz+120Hz : 120Hz Panel+120Hz Backlight 240Hz (60HZ Input) : Embedded MEMC Circuit Touchscreen Without Signal Type LVDS (1 ch, 8-bit) , Connector 20 pins Voltage Supply 3.3V (Typ.) Max. Ratings Storage Temp.: -20 ~ 60 °C    Operating Temp.: 0 ~ 50 °C  CLAA150XP07Q inverter, CLAA150XP07Q power supply, CLAA150XP07Q electronic board, CLAA150XP07Q VGA board, CLAA150XP07Q touchscreen available.
