Manufacturer Sharp Model Name LQ084S3DG01R Screen Size 8.4 inch Screen Type LCM, a-Si TFT-LCD Pixel Number 800(RGB)×600 (SVGA) 119PPI Arrangement RGB Vertical Stripe Active Area(mm) 170.4 × 127.8 (H×V) Outline(mm) 199.5 × 149.5 (H×V×D) Bezel Area(mm) 175.15 × 133.1 (H×V) Luminance 350 cd/m² (Typ.)Contrast Ratio250 : 1 (Typ.) (TM) Viewing Angle 65/65/45/65 (Typ.)(CR≥5) Left / Right / Up / Down Response 20/40 (Typ.)(Tr/Td) ms Good View at 6 o'clock Work Mode TN, Normally White, Transmissive Color Depth 262K Backlight 2 pcs CCFL , 50K hours , No Driver Mass 405g (Max.)Used forIndustrial Refresh Rate 60Hz 120Hz (60HZ Input) : Embedded MEMC Circuit 120Hz+120Hz : 120Hz Panel+120Hz Backlight 240Hz (60HZ Input) : Embedded MEMC Circuit Touchscreen Without Signal Type Parallel RGB (1 ch, 6-bit) , 30 pins Connector Voltage Supply 3.3V (Typ.) Max. Ratings Storage Temp.: -25 ~ 70 °C Operating Temp.: -10 ~ 65 °C LQ084S3DG01R inverter, LQ084S3DG01R power supply, LQ084S3DG01R electronic board, LQ084S3DG01R VGA board, LQ084S3DG01R touchscreen available.
