Content last revised on May 27, 2023
Manufacturer Part Number: MJF6388GBrand Name: ON SemiconductorPbfree Code: ActiveIhs Manufacturer: ON SEMICONDUCTORPart Package Code: TO-220ABPackage Description: FLANGE MOUNT, R-PSFM-T3Pin Count: 3Manufacturer Package Code: 221D-03ECCN Code: EAR99HTS Code: 8541.29.00.95Manufacturer: ON SemiconductorRisk Rank: 0.82Additional Feature: UL RECOGNIZEDCase Connection: ISOLATEDCollector Current-Max (IC): 10 ACollector-Emitter Voltage-Max: 100 VConfiguration: DARLINGTON WITH BUILT-IN DIODE AND RESISTORDC Current Gain-Min (hFE): 100JEDEC-95 Code: TO-220ABJESD-30 Code: R-PSFM-T3JESD-609 Code: e3Number of Elements: 1Number of Terminals: 3Operating Temperature-Max: 150 °CPackage Body Material: PLASTIC/EPOXYPackage Shape: RECTANGULARPackage Style: FLANGE MOUNTPeak Reflow Temperature (Cel): 260Polarity/Channel Type: NPNPower Dissipation-Max (Abs): 40 WQualification Status: Not QualifiedSubcategory: Other TransistorsSurface Mount: NOTerminal Finish: Tin (Sn)Terminal Form: THROUGH-HOLETerminal Position: SINGLETime 10 A, 100 V NPN Bipolar Power Transistor, TO-220 3 LEAD FULLPAK, 50-TUBE
