Manufacturer Part Number: RB558WTLPbfree Code: YesPart Life Cycle Code: Not RecommendedIhs Manufacturer: Rohm CO LTDPackage Description: R-PDSO-G3ECCN Code: EAR99HTS Code: 8541.10.00.70Manufacturer: ROHM SemiconductorRisk Rank: 7.49Additional Feature: HIGH RELIABILITYConfiguration: SERIES CONNECTED, CENTER TAP, 2 ELEMENTSDiode Element Material: SILICONDiode Type: RECTIFIER DIODEForward Voltage-Max (VF): 0.35 VJESD-30 Code: R-PDSO-G3Non-rep Pk Forward Current-Max: 0.5 ANumber of Elements: 2Number of Terminals: 3Operating Temperature-Max: 125 °COutput Current-Max: 0.1 APackage Body Material: PLASTIC/EPOXYPackage Shape: RECTANGULARPackage Style: SMALL OUTLINEPeak Reflow Temperature (Cel): NOT SPECIFIEDRep Pk Reverse Voltage-Max: 30 VSubcategory: Rectifier DiodesSurface Mount: YESTechnology: SCHOTTKYTerminal Form: GULL WINGTerminal Position: DUALTime Rectifier Diode, Schottky, 2 Element, 0.1A, 30V V(RRM), Silicon, SC-75A, 3 PIN
