Content last revised on May 25, 2023
Manufacturer Part Number: SK40GB123Pbfree Code: YesPart Life Cycle Code: ObsoleteIhs Manufacturer: Semikron INTERNATIONALPackage Description: FLANGE MOUNT, R-XUFM-X5Pin Count: 8Manufacturer Package Code: CASE T32Manufacturer: SEMIKRONRisk Rank: 5.66Additional Feature: UL RECOGNIZEDCase Connection: ISOLATEDCollector Current-Max (IC): 40 ACollector-Emitter Voltage-Max: 1200 VConfiguration: SERIES CONNECTED, CENTER TAP, 2 ELEMENTS WITH BUILT-IN DIODEGate-Emitter Voltage-Max: 20 VJESD-30 Code: R-XUFM-X5JESD-609 Code: e3/e4Number of Elements: 2Number of Terminals: 5Operating Temperature-Max: 150 °CPackage Body Material: UNSPECIFIEDPackage Shape: RECTANGULARPackage Style: FLANGE MOUNTPeak Reflow Temperature (Cel): NOT SPECIFIEDPolarity/Channel Type: N-CHANNELQualification Status: Not QualifiedSubcategory: Insulated Gate BIP TransistorsSurface Mount: NOTerminal Finish: TIN/SILVERTerminal Form: UNSPECIFIEDTerminal Position: UPPERTime Insulated Gate Bipolar Transistor, 40A I(C), 1200V V(BR)CES, N-Channel, CASE T32, SEMITOP-8
