#SEMIKRON, #SK70DH08, #IGBT_Module, #IGBT, SK70DH08 Silicon Controlled Rectifier, 68000mA I(T), 800V V(DRM), 800V V(RRM), 3 Element, CASE T40, SEMITOP-28; SK70DH08
Manufacturer Part Number: SK70DH08Pbfree Code: YesPart Life Cycle Code: ActiveIhs Manufacturer: Semikron INTERNATIONALPackage Description: CASE T40, SEMITOP-28Pin Count: 28Manufacturer Package Code: CASE T40HTS Code: 8541.30.00.80Manufacturer: SemikronRisk Rank: 5.71Additional Feature: UL RECOGNIZEDCase Connection: ISOLATEDConfiguration: 3 PHASE BRIDGE, HALF-CONTROLLED, COMMON CATHODEDC Gate Trigger Current-Max: 100 mADC Gate Trigger Voltage-Max: 2 VDesc. of Quick-Connects: 0Desc. of Screw Terminals: 0Holding Current-Max: 150 mAJESD-30 Code: R-XUFM-X28JESD-609 Code: e3/e4Leakage Current-Max: 10 mANon-Repetitive Pk On-state Cur: 270 ANumber of Elements: 3Number of Terminals: 28On-state Current-Max: 68000 AOperating Temperature-Max: 150 °COperating Temperature-Min: -40 °CPackage Body Material: UNSPECIFIEDPackage Shape: RECTANGULARPackage Style: FLANGE MOUNTPeak Reflow Temperature (Cel): NOT SPECIFIEDQualification Status: Not QualifiedRepetitive Peak Off-state Voltage: 800 VRepetitive Peak Reverse Voltage: 800 VSubcategory: Silicon Controlled RectifiersSurface Mount: NOTerminal Finish: TIN/SILVERTerminal Form: UNSPECIFIEDTerminal Position: UPPERTime Silicon Controlled Rectifier, 68000mA I(T), 800V V(DRM), 800V V(RRM), 3 Element, CASE T40, SEMITOP-28
