Manufacturer Part Number: SKT290F04DTPart Life Cycle Code: ObsoleteIhs Manufacturer: Semikron INTERNATIONALPackage Description: DISK BUTTON, O-CEDB-N2HTS Code: 8541.30.00.80Manufacturer: SemikronRisk Rank: 5.82Additional Feature: FASTCircuit Commutated Turn-off Time-Nom: 20 µsConfiguration: SINGLECritical Rate of Rise of Off-State Voltage-Min: 500 V/usDC Gate Trigger Current-Max: 250 mADC Gate Trigger Voltage-Max: 4 VHolding Current-Max: 400 mAJEDEC-95 Code: TO-200ABJESD-30 Code: O-CEDB-N2Leakage Current-Max: 70 mANon-Repetitive Pk On-state Cur: 5000 ANumber of Elements: 1Number of Terminals: 2On-state Current-Max: 290000 AOperating Temperature-Max: 125 °COperating Temperature-Min: -40 °CPackage Body Material: CERAMIC, METAL-SEALED COFIREDPackage Shape: ROUNDPackage Style: DISK BUTTONQualification Status: Not QualifiedRMS On-state Current-Max: 600 ARepetitive Peak Off-state Leakage Current-Max: 70000 µARepetitive Peak Off-state Voltage: 400 VRepetitive Peak Reverse Voltage: 400 VSubcategory: Silicon Controlled RectifiersSurface Mount: YESTerminal Form: NO LEADTerminal Position: ENDTrigger Device Type: SCR Silicon Controlled Rectifier, 600A I(T)RMS, 290000mA I(T), 400V V(DRM), 400V V(RRM), 1 Element, TO-200AB
