Ampire AM-1024768RTNQW-00H LCD Display

Brand AMPIRE

Model P/N AM-1024768RTNQW-00H

Diagonal Size 12.1 inch

Panel Type a-Si TFT-LCD, LCM

Resolution 1024(RGB)×768, XGA 105PPI

Pixel Format RGB Vertical Stripe

Active Area 245.76(W)×184.32(H) mm

Outline Size 279(W)×209(H) ×9(D) mm

Surface Antiglare, Hard coating (3H)

Brightness 300 cd/m² (Typ.)

Contrast Ratio 800:1 (Typ.) (TM)

Viewing Angle 80/80/80/80 (Typ.)(CR≥10) Left / Right / Up / Down

Display Mode TN, Normally White, Transmissive

IPS Family: AAS, ADS, AHVA, FFS, HIS, IPS, New Mode2, PLS, SFT, Vistarich

VA Family: ASV, FSA, HVA, MVA, PVA, SVA, UV²A, VA

Response Time16 (Typ.)(Tr+Td)

Display Colors 262K/16.7M

Lamp Type WLED , 30K hours , With LED Driver

Frequency 60Hz

Touch Screen Without

Panel Weight 545g (Max.)

Application Industrial

Signal Interface LVDS (1 ch, 6/8-bit) , 20 pins Connector

Input Voltage 3.3V (Typ.)

Environment Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C
