- Brand: AMPIRE
- Model: AM-800600K3TMQW-T01H
- Diagonal Size: 10.4 inches
- Panel Type: a-Si TFT-LCD, LCM
- Resolution: 800 x 600 (SVGA)
- Pixel Format: RGB Vertical Stripe
- Active Area: 211.2 (W) x 158.4 (H) mm
- Bezel Opening: 214.8 (W) x 162.7 (H) mm
- Outline Dimensions: 243 (W) x 185.6 (H) x 9.26 (D) mm
- Treatment: Surface treatment not specified
- Luminance: 800 cd/m² (Typical)
- Contrast Ratio: 500:1 (Typical)
- Response Time: 5/15 (Typical, Tr/Td) ms
- Display Mode: TN (Twisted Nematic), Normally White, Transmissive
- Support Color: 262K, which is equivalent to 50% NTSC
- Mass: Not specified
- Refresh Rate: 60Hz, with options for 120Hz and 240Hz using MEMC circuit
- Backlight: WLED (White LED) with a lifetime of 50,000 hours and an LED driver
- Touchscreen: 4-wire Resistive Touch
- Application: Outdoor High Brightness Automotive Display
- Signal Interface: LVDS (1 channel, 6-bit), 20 pins Connector
- Voltage Supply: 3.3V (Typical)
- Operating Temperature: -20 ~ 70 °C
- Storage Temperature: -30 ~ 80 °C
