Content last revised on December 13, 2023
Manufacturer Part Number: APTGT600A60GPbfree Code: YesPart Life Cycle Code: ActiveIhs Manufacturer: MICROSEMI CORPPackage Description: FLANGE MOUNT, R-XUFM-X7Pin Count: 7ECCN Code: EAR99Manufacturer: Microsemi CorporationRisk Rank: 1.41Additional Feature: AVALANCHE RATEDCase Connection: ISOLATEDCollector Current-Max (IC): 700 ACollector-Emitter Voltage-Max: 600 VConfiguration: SERIES CONNECTED, CENTER TAP, 2 ELEMENTS WITH BUILT-IN DIODEJESD-30 Code: R-XUFM-X7JESD-609 Code: e1Number of Elements: 2Number of Terminals: 7Operating Temperature-Max: 175 °CPackage Body Material: UNSPECIFIEDPackage Shape: RECTANGULARPackage Style: FLANGE MOUNTPeak Reflow Temperature (Cel): NOT SPECIFIEDPolarity/Channel Type: N-CHANNELQualification Status: Not QualifiedSurface Mount: NOTerminal Finish: TIN SILVER COPPERTerminal Form: UNSPECIFIEDTerminal Position: UPPERTime Insulated Gate Bipolar Transistor, 700A I(C), 600V V(BR)CES, N-Channel, ROHS COMPLIANT, SP6, 7 PIN
