Content last revised on March 25, 2025
Brand Innolux
Model AT080TN03 V.2
Diagonal Size 8.0 inch
Type a-Si TFT-LCD, LCM
Pixel Format 800(RGB)×480 [WVGA] 116PPI
Configuration RGB Vertical Stripe
Active Area 176.64(H)×99.36(V) mm
Outline Dim 192.8(H)×116.9(V) mm
Bezel Area 180.1(H)×103.4(V) mm
Treatment Antiglare
Luminance 500 cd/m² (Typ.)
Contrast Ratio 300:1 (Typ.) (TM)
View Direction 6 o'clock
Response Time 15/20 (Typ.)(Tr/Td)
Viewing Angle 65/65/45/65 (Typ.)(CR≥10) Left / Right / Up / Down
Operating Mode TN, Normally White, Transmissive
Support Color 262K
Light Source WLED [3S12P] , 20K hours , W/O Driver
Weight 235g (Typ.)
Designed For Automotive Display
Touch Panel Without
Interface Type Parallel RGB (1 ch, 6-bit) , 60 pins FPC
Power Supply 3.3/10.0/15.0/-10.0V (Typ.)(VCC/AVDD/VGH/VGL)
Environment Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -30 ~ 85 °C
