Content last revised on November 21, 2024
Panel Brand AUO ptronics
Panel Model B104SN02 V0
Panel Size 10.4 inch
Panel Type a-Si TFT-LCD, LCM
Resolution 800(RGB)×600, SVGA, 96PPI
Pixel Format RGB Vertical Stripe
Display Area 211.2(W)×158.4(H) mm
Bezel Opening 215.6(W)×162.7(H) mm
Outline Size 243(W)×184(H) mm
Brightness 400 cd/m² (Typ.)
Contrast Ratio 500:1 (Typ.) (TM)
Viewing Angle 60/60/40/60 (Typ.)(CR≥10) Left / Right / Up / Down
Display Mode TN, Normally White, Transmissive
Best View on 6 o'clock
Response Time 35 (Typ.)(Tr+Td)
Display Colors 262K 49% NTSC
Lamp Type 2 pcs CCFL , 50K hours , Without Driver
Frequency 60Hz
Touch Screen Without
Panel Weight 485g (Typ.)
Application Industrial
Signal Interface LVDS (1 ch, 6-bit) , 20 pins Connector
Input Voltage 3.3V (Typ.)
Environment Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C
