Content last revised on March 5, 2025
Manufacturer Planar
Model Name EL512.256-H3 FRB
Screen Size 8.6 inch
Screen Type EL, EL
Pixel Number 512×256 66PPI
Arrangement Rectangle
Active Area(mm) 195.1 × 97.5 (H×V)
Outline(mm) 233 × 136 (H×V×D)
Luminance 65 cd/m² (Typ.)
Color Depth Monochrome Backlightself , 30K hours
Mass 400g
Used for Industrial
Refresh Rate 70Hz
120Hz (60HZ Input) : Embedded MEMC Circuit
120Hz+120Hz : 120Hz Panel+120Hz Backlight
240Hz (60HZ Input) : Embedded MEMC Circuit
Touchscreen Without
Voltage Supply 5/(11~30))V (Typ.)(VCC1/VCC2)
Max. Ratings Storage Temp.: -40 ~ 75 °C Operating Temp.: -25 ~ 65 °C
