Content last revised on August 19, 2025
Manufacturer Part Number: FPAB30BH60B
Brand Name: ON Semiconductor
Pbfree Code: Active
Ihs Manufacturer: ON SEMICONDUCTOR
Package Description: , MODULE,27LEAD,1.2
Manufacturer Package Code: MODDJ
ECCN Code: EAR99
HTS Code: 8541.29.00.95
Manufacturer: ON Semiconductor
Risk Rank: 1.21
Analog IC - Other Type: AC MOTOR CONTROLLER
JESD-30 Code: R-XZFM-T27
Number of Functions: 1
Number of Terminals: 27
Output Current-Max: 60 A
Package Body Material: UNSPECIFIED
Package Equivalence Code: MODULE,27LEAD,1.2
Package Shape: RECTANGULAR
Package Style: FLANGE MOUNT
Peak Reflow Temperature (Cel): NOT SPECIFIED
Power Supplies: 15 V
Qualification Status: Not Qualified
Subcategory: Switching Regulator or Controllers
Supply Current-Max (Isup): 26 mA
Supply Voltage-Max (Vsup): 16.5 V
Supply Voltage-Min (Vsup): 13.5 V
Supply Voltage-Nom (Vsup): 15 V
Surface Mount: NO
Terminal Form: THROUGH-HOLE
Terminal Position: ZIG-ZAG
Time
PFC Intelligent Power Module, 600V, 30A, 60-TUBE
