Content last revised on June 27, 2023
Manufacturer Innolux Model Name G057AGB-T01 Screen Size 7.0 inch Screen Type LCM , a-Si TFT-LCD Pixel Number 800(RGB)×480 (WVGA) 133PPI Arrangement RGB Vertical Stripe Active Area(mm) 152.4 × 91.44 (H×V) Outline(mm) 165 × 104 × 6.83 (H×V×D) Bezel Area(mm) 154.6 × 93.64 (H×V) Treatment Antiglare, Hard coating (3H) Luminance 500 cd/m² (Typ.) Contrast Ratio 600 : 1 (Typ.) (TM) Viewing Angle 70/70/60/60 (Typ.)(CR≥10) Left / Right / Up / Down Response 5/11 (Typ.)(Tr/Td) ms Work Mode TN, Normally White, Transmissive Color Depth 262K/16.2M 72% NTSC Backlight 7S2P WLED , 50K hours , No Driver Mass 132±15gUsed forAutomotive Display Industrial Refresh Rate 60HzTouchscreenWithout Signal Type TTL (1 ch, 6/8-bit) , 60 pins FPC Voltage Supply 3.3/10/19/-6.8V (Typ.)(VCC/AVDD/VGH/VGL) Max. Ratings Storage Temp.: -40 ~ 95 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 3.0G (29.4 m/s²) G057AGB-T01 inverter, G057AGB-T01 power supply, G057AGB-T01 electronic board, G057AGB-T01 VGA board, G057AGB-T01 touchscreen available.
