BrandAUOModel: G070VTN01.0
Diagonal Size: 7.0 inch
Type: a-Si TFT-LCD, LCM
Pixel Format: 800×480(RGB) [WVGA]
Configuration: RGB Horizontal Stripe
Active Area: 152.4(H)×91.44(V) mm
Outline Dim. 170(H)×111(V) ×8.3(D) mm
Bezel Area: 155.2(H)×92.84(V) mm
Treatment: Antiglare, Hard coating (3H)
Luminance: 300 cd/m² (Typ.)
Contrast Ratio: 500:1 (Typ.) (TM)
View Direction: 6 o'clock
Response Time: 12/18 (Typ.)(Tr/Td)
Viewing Angle: 65/65/50/60 (Typ.)(CR≥10) Left / Right / Up / DownOperating Mode TN, Normally White, Transmissive
Support Color: 262K/16.2M 50% (CIE1931)
Light Source:WLED [3S7P] , 30K hours , W/O Driver
Weight: 180g
Frame Rate: 60Hz
Touch Panel: Without
Interface Type: 20 pins LVDS (1 ch, 6/8-bit) , Connector
Power Supply: 3.3V (Typ.)
Environment: Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C
