Manufacturer AUO
Model Name G070VVN01.2
Screen Size 7.0 inch
Pixel Number 800(RGB)×480 (WVGA) 133PPI
Active Area(mm) 152.4 × 91.44 (H×V)
Bezel Area(mm) 154.2 × 93.24 (H×V)
Luminance 600 (Typ.)(cd/m²)
Viewing Angle 80/80/80/80 (Typ.)(CR≥10)
Good View at Symmetry
Color Depth 262K/16.2M 50% NTSC
Contrast Ratio 1500:1 (Typ.) (TM)
Frequency 60Hz
Panel Type LCM , a-Si TFT-LCD
Arrangement RGB Vertical Stripe
Outline Size 164.55(W)×104.71(H) ×8.5(D) mm
Surface Antiglare, Hard coating (3H)
Contrast Ratio 1500 : 1 (Typ.) (TM)
display Mode AMVA3, Normally Black, Transmissive
Response Time 10/25 (Typ.)(Tr/Td) ms
Lamp Type 7S2P WLED , 30K hours , No Driver
Touchscreen Without
Signal Type Parallel RGB (1 ch, 6/8-bit) , 50 pins Connector
Voltage Supply 3.3V (Typ.)
Max. Ratings Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C
