AUO G101EVN03.1 | High-Brightness Industrial LCD with Wide Viewing Angle Technology
The AUO G101EVN03.1 is a 10.1-inch industrial-grade TFT-LCD module engineered for applications where visual clarity, color consistency, and operational reliability are non-negotiable. It combines a high-resolution WXGA (1280x800) display with superior optical performance, making it an ideal human-machine interface (HMI) solution for a diverse range of demanding sectors.
- Brand: AUO
- Model: G101EVN03.1
- Core Function: 10.1" WXGA Industrial Display
- Key Strengths: 500-nit high brightness, wide viewing angles, extended operating temperature range.
- Typical Applications: Medical imaging stations, industrial control panels, marine navigation systems, and high-end POS terminals.
Technical Deep Dive: Beyond the Spec Sheet
Understanding the core technology of the G101EVN03.1 reveals why it outperforms consumer-grade displays in professional settings. Two features are particularly critical for system designers.
-
Advanced MVA Technology for Uncompromised Viewing
Unlike standard TN (Twisted Nematic) panels that suffer from significant color and contrast shifts at off-axis angles, the AUO G101EVN03.1 utilizes Multi-domain Vertical Alignment (MVA) technology. This provides symmetrical, ultra-wide viewing angles of 89/89/89/89 degrees. For application designers, this means diagnostic images on a medical cart or process data on a factory control panel remain accurate and legible, regardless of the operator's position. This consistency is crucial for collaborative environments and preventing costly operational errors.
-
High Brightness & Contrast for Demanding Environments
With a brightness of 500 cd/m² and a high contrast ratio of 1300:1, this display delivers crisp, vibrant images that cut through high ambient light. The powerful WLED backlight system not only ensures excellent readability but is also designed for longevity, a key factor in reducing maintenance cycles and total cost of ownership. This performance makes the screen viable for semi-outdoor applications like ticketing kiosks or on-deck marine equipment when properly integrated.
Multi-Dimensional Application Scenarios
The technical strengths of the AUO G101EVN03.1 translate directly into tangible benefits across several key industries.
- Medical Imaging & Diagnostics: The combination of high contrast and consistent wide-angle viewing ensures that medical professionals see precise, unaltered grayscale and color images, aiding in accurate diagnoses.
- Industrial Automation HMI: Its robust design and wide operating temperature range (-20°C to 70°C) guarantee stable performance in harsh factory environments. Integrating such a component requires careful attention to ESD protection to ensure system longevity.
- Marine & Avionics Displays: High brightness and an anti-glare surface treatment are essential for chart plotters and cockpit displays, where direct sunlight can render lesser screens unreadable. The LVDS interface ensures stable signal transmission amidst the electronic noise common in these settings.
- Transportation & Public Information Systems: For digital signage in transit hubs or vehicle information displays, the G101EVN03.1's durability and clear visibility ensure information is conveyed effectively to the public.
Key Technical Specifications
| Parameter | Value |
|---|---|
| Screen Size | 10.1 inch |
| Resolution | 1280 (RGB) × 800 (WXGA) |
| Brightness | 500 cd/m² (Typ.) |
| Contrast Ratio | 1300:1 (Typ.) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Signal Interface | LVDS (1 ch, 6/8-bit), 40 pins Connector |
| Operating Temperature | -20 ~ 70 °C |
| Backlight | WLED, 30K hours, with LED Driver |
For a comprehensive list of parameters, please refer to the official G101EVN03.1 Datasheet.
Integration & Design-In Considerations
The LVDS (Low-Voltage Differential Signaling) interface of the G101EVN03.1 is a key advantage for complex systems, offering high noise immunity and allowing for longer cable runs between the display and the controller board. To maximize performance, engineers should implement proper grounding and consider using an EMI filter in the power supply line to prevent interference. Furthermore, this module adheres to stringent manufacturing standards, ensuring RoHS compliance for products intended for the global market.
For systems requiring a display that offers a blend of visual excellence, ruggedness, and long-term availability, the AUO G101EVN03.1 presents a superior choice. If your project demands specific modifications or you need assistance with integration, please contact our technical support team. You can also explore our complete catalog of industrial LCD modules for other options.
