#Innolux, #G101ICE_L01, #LCD_Display, #LCD, G101ICE-L01 Innolux 10.1 inch LCM 1280×800 500 800:1 85/85/85/85 262K/16.2M WLED LVDS
The Innolux P/N: G101ICE-L01:
Diagonal Size: 10.1 inches.
Panel Type: Active-Matrix Thin-Film Transistor Liquid Crystal Display (a-Si TFT-LCD).
Resolution: 1280 x 800 pixels, which is WXGA (Wide Extended Graphics Array) resolution, providing a pixel density of 149 pixels per inch (PPI).
Pixel Format: RGB Vertical Stripe.
Active Area: The part of the screen that displays images measures 216.96 mm in width and 135.6 mm in height.
Bezel Opening: The opening in the device's frame for the screen is 218.96 mm in width and 137.6 mm in height.
Outline Dimensions: The physical dimensions of the panel are 230.7 mm in width, 152.55 mm in height, and 7 mm in depth.
Treatment: The screen has an antiglare surface and is hard-coated with a 3H hardness rating.
Luminance: The typical brightness of the display is 500 cd/m² (candelas per square meter).
Contrast Ratio: The typical contrast ratio is 800:1.
Viewing Angle: The typical viewing angles are 85 degrees in all directions (left, right, up, and down) when the contrast ratio is greater than or equal to 10.
Response Time: The panel has a typical response time of 14 ms for the rise time (Tr) and 11 ms for the fall time (Td).
Good View at: This panel is designed for symmetric viewing and operates in AAS (Advanced Super View) mode. It is normally black and transmissive.
Color Depth: The panel supports 262K colors, which is approximately 16.2 million colors, covering 52% of the NTSC color gamut.
Backlight: The backlight is a WLED (White Light Emitting Diode) with a rated lifespan of 50,000 hours. It comes with an integrated LED driver.
Mass: The typical weight of the panel is 360 grams, with a maximum weight of 375 grams. This panel is designed for industrial use.
Refresh Rate: The panel has a standard 60Hz refresh rate, but it also supports a 120Hz refresh rate with embedded MEMC (Motion Estimation, Motion Compensation) circuitry when provided with a 60Hz input. It can achieve a 240Hz refresh rate with the same MEMC circuitry.
Touchscreen: This panel does not have a touchscreen feature.
Signal Type: It uses LVDS (Low Voltage Differential Signaling) with a 1-channel, 6/8-bit configuration and is connected via a 40-pin connector.
Voltage Supply: The typical voltage supply for this panel is 3.3V.
Max. Ratings: The storage temperature range is -25 to 70°C, and the operating temperature range is -20 to 70°C.
