AUO G215HAN01.2 LCD Display

Manufacturer AUO

Model Name G215HAN01.2

Screen Size 21.5 inch

Screen TypeLCM,   a-Si TFT-LCD

Pixel Number 1920(RGB)×1080   (FHD)  102PPI

Arrangement RGB Vertical Stripe

Active Area(mm) 476.064 × 267.786 (H×V)

Outline(mm) 497.6 × 292.2 × 11 (H×V×D)

Bezel Area(mm) 479.8 × 271.3 (H×V)

Treatment Antiglare, Hard coating (3H)

Luminance 350 cd/m² (Typ.)

Contrast Ratio 1000 : 1 (Typ.) (TM)

Viewing Angle 89/89/89/89 (Typ.)(CR≥10) Left / Right / Up / Down

Response 12/10 (Typ.)(Tr/Td) ms

Good View at Symmetry

Work Mode AHVA, Normally Black, Transmissive

Color Depth 16.7M   72% NTSC

Backlight 12S4P WLED , 50K hours , No Driver

Mass1.74Kgs (Typ.)

Used for Industrial Medical Imaging

Refresh Rate 60Hz

120Hz (60HZ Input) : Embedded MEMC Circuit

120Hz+120Hz : 120Hz Panel+120Hz Backlight

240Hz (60HZ Input) : Embedded MEMC Circuit

Touchscreen Without

Signal Type LVDS (2 ch, 8-bit) , Connector 30 pins

Voltage Supply 5.0V (Typ.)

Max. Ratings Storage Temp.: -20 ~ 60 °C    Operating Temp.: 0 ~ 60 °C
