Content last revised on December 6, 2023
Panel Brand AUO Panel Model G270ZAN01.0 Panel Size 27.0" Panel Type a-Si TFT-LCD , LCM Resolution 3840(RGB)×2160, UHD, 163PPI Pixel Format RGB Vertical Stripe Display Area 596.16(W)×335.34(H) mm Bezel Opening 602.0(W)×340.4(H) mm Outline Size 630(W)×368.2(H) ×23.4(D) mm Surface Antiglare Brightness 800 cd/m² (Typ.) Contrast Ratio 1000:1 (Typ.) (TM) Viewing Angle 89/89/89/89 (Typ.)(CR≥10) Display Mode AHVA, Normally Black, Transmissive Best View on Symmetry Response Time 16/25 (Typ./Max.)(Tr+Td) Display Colors 1.07B 94% NTSC Lamp Type WLED , 30K hours , With LED Driver Frequency 60Hz Touch Screen Without Weight 3.40Kgs (Typ.) Application Signal Interface eDP (2 ch, 4 Lanes) , HBR1 (2.7G / lane) , 51 pins Connector Input Voltage 12.0V (Typ.) Environment Operating Temp.: 0 ~ 40 °C ; Storage Temp.: -20 ~ 50 °C G270ZAN01.0 inverter, G270ZAN01.0 power supply, G270ZAN01.0 electronic board, G270ZAN01.0 VGA board, G270ZAN01.0 touchscreen available.
