Content last revised on June 28, 2023
Manufacturer AUO Model Name G270ZAN01.5 Screen Size 27.0 inch Screen Type LCM, a-Si TFT-LCD Pixel Number 3840(RGB)×2160 (UHD) 163PPI ] Arrangement RGB Vertical Stripe Active Area(mm) 596.16 × 335.34 (H×V) Outline(mm) 613.6 × 356.85 × 14.95 (H×V×D) Bezel Area(mm) 601.6 × 340.16 (H×V) Treatment Antiglare, Hard coating (3H) Luminance 400 cd/m² (Typ.) Contrast Ratio 1000 : 1 (Typ.) (TM) Viewing Angle 89/89/89/89 (Typ.)(CR≥10) Left / Right / Up / Down Response 16/25 (Typ./Max.)(Tr+Td) ms Good View at Symmetry Work Mode AHVA, Normally Black, Transmissive Color Depth 1.07B 93% NTSC Backlight 11S4P×2CN WLED , 50K hours , No Driver Mass 3.30Kgs (Typ.) Used for Industrial Medical Imaging Refresh Rate 60Hz 120Hz (60HZ Input) : Embedded MEMC Circuit 120Hz+120Hz : 120Hz Panel+120Hz Backlight 240Hz (60HZ Input) : Embedded MEMC Circuit Touchscreen Without Signal Type eDP (4 Lanes) , HBR2 (5.4G / lane) , Connector 51 pins Voltage Supply 12.0V (Typ.) Max. Ratings Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C G270ZAN01.5 inverter, G270ZAN01.5 power supply, G270ZAN01.5 electronic board, G270ZAN01.5 VGA board, G270ZAN01.5 touchscreen available.
