Proface GP577R-TC11 LCD Display

The following items are included in the package. Before using, please en-sure everything is there.

This unit has been carefully packed, with special attention to quality. How-ever, should you find anything damaged or missing, please contact yourlocal GP distributor immediately.

Cables

Adapters

Screen editor software are optionally available.

For more information, see Digital's cata-logues.

Display The monitor screen that indicates screens and data of the host.

Touch PanelRuns any screen change operations and sendsdata to the PLC.

Power LampLights up when the power is turned On. (GreenLED)

Power Input Terminal BlockThe input and ground terminals for AC powercable.

Auxiliary Input/Output (AUX) Operates the Touch Switch, System Alarm, Buzzer, Run outputs, and Remote Reset inputs.

Serial Interface RS-232C, RS-422 (Serial) interface. Connect tothe Host.

Printer Interface Connect the printer here.

Tool ConnectorConnect the Downloading Cable, or a Bar CodeReader here.

Frame ground 5V±5% output 14 VCC 0.25 A

Use rough metric type M2.6 x 0.45p threads used to hold the cable'sset (fastening) screws in place.

The AUX Alarm outputs in the following two cases:

• Hardware Alarm (SCREEN MEMORY CHECKSUM ERROR)

• Software Alarm (SYSTEM ERROR, incorrect data that makes continuation of screen operation impossible.)
