Content last revised on November 3, 2024
Panel Brand : LG Display
Panel Model : LB104V03-TD01 1 Compatible model
Panel Type : a-Si TFT-LCD , Panel
Panel Size : 10.4 inch
Resolution : 640(RGB)×480 , VGA
Display Mode : TN, Normally White, Transmissive
Active Area : 211.2×158.4 mm
Outline : 236×180×8 mm
Surface : Antiglare, Hard coating (3H)
Brightness : 400 cd/m² (Typ.)
Contrast Ratio : 300:1 (Typ.)
Display Colors : 262K (6-bit)
Response Time : 5/25 (Typ.)(Tr/Td)
Viewing Angle : 60/60/40/50 (Typ.)(CR≥10) (L/R/U/D)
Frequency : 60Hz
Lamp Type : 2 pcs CCFL
Signal Interface : Parallel RGB (1 ch, 6-bit)
Input Voltage : 3.3V (Typ.)
