Content last revised on November 13, 2024
Manufacturer LG.Philips LCD
Model Name LM150X08-B5
Screen Size 15.0 inch
Screen Type LCM, a-Si TFT-LCD
Pixel Number 1024(RGB)×768 (XGA) 85PPI
Arrangement RGB Vertical Stripe
Active Area(mm) 304.128 × 228.096 (H×V)
Outline(mm) 326.5 × 253.5 × 11.7 (H×V×D)
Bezel Area(mm) 307.4 × 231.3 (H×V)
Treatment Antiglare (Haze 13%), Hard coating (3H)
Luminance 300 cd/m² (Typ.)
Contrast Ratio 400 : 1 (Typ.) (TM)
Viewing Angle 65/65/45/55 (Typ.)(CR≥10) Left / Right / Up / Down
Response 5/11 (Typ.)(Tr/Td) ms
Good View at 6 o'clock
Work Mode TN, Normally White, Transmissive
Color Depth 16.2M 60% NTSC
Backlight 2 pcs CCFL , 40K hours , No Driver
Weight 1.00Kgs (Typ.)
Used for Desktop Monitor
Refresh Rate 60Hz
120Hz (60HZ Input) : Embedded MEMC Circuit
120Hz+120Hz : 120Hz Panel+120Hz Backlight
240Hz (60HZ Input) : Embedded MEMC Circuit
Touchscreen Without
Signal Type LVDS (1 ch, 8-bit) , 20 pins Connector
Voltage Supply 3.3V (Typ.)
Max. Ratings Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C
