Panel Brand : Toshiba Matsushita
Panel Model : LTA150B851F
Panel Type : a-Si TFT-LCD , Panel
Panel Size : 15.0 inch
Resolution : 1024(RGB)×768 , XGA
Display Mode : TN, Normally White, Transmissive
Active Area : 304.128×228.096 mm
Outline : 348×254.7 mm
Brightness : 450 cd/m² (Typ.)
Contrast Ratio : 450:1 (Typ.)
Display Colors : 16.7M (8-bit)
Response Time : 16 (Typ.)(Tr+Td)
Viewing Angle : 80/80/45/75 (Typ.)(CR≥10) (L/R/U/D)
Lamp Type : 4 pcs CCFL Without Driver
Signal Interface : LVDS (1 ch, 8-bit) , 22 pins
Input Voltage : 3.3V (Typ.)
Environment Operating Temperature: -10 ~ 70 °C ; Storage Temperature: -20 ~ 80 °C
