Content last revised on May 22, 2023
Brand Hitachi Model TX26D01VM1CAA Diagonal Size 10.4 inch Type a-Si TFT-LCD , LCM Pixel Format 640(RGB)×480 [VGA] 76PPI Configuration RGB Vertical Stripe Active Area 211.2(H)×158.4(V) mm Outline Dim. 243(H)×181.6(V) ×12.5(D) mm Bezel Area 215.4(H)×162.6(V) mm Treatment Antiglare, Hard coating (3H) Luminance 350 cd/m² (Typ.) Contrast Ratio 500:1 (Typ.) (TM) Response Time 30/20 (Typ.)(Tr/Td) Viewing Angle 50/50/50/50 (Min.)(CR≥10) Left / Right / Up / Down Operating Mode TN, Normally White, Transmissive IPS Family: AAS, ADS, AHVA, FFS, IPS, New Mode2, PLS, SFT, Vistarich VA Family: ASV, HVA, MVA, PVA, SVA, UV²A, VA Support Color 262K 63% NTSC Light Source CCFL [2 pcs] , W/O Driver Weight 450g (Typ.) Designed For Industrial Frame Rate 60Hz 120Hz (60HZ Input) : Embedded MEMC Circuit 120Hz+120Hz : 120Hz Panel+120Hz Backlight 240Hz (60HZ Input) : Embedded MEMC Circuit Touch Panel Without Interface Type CMOS (1 ch, 6-bit) , 32 pins Connector Power Supply 3.3V (Typ.)(VDD) Environment Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -20 ~ 70 °C ; Vibration Level: 3.0G (29.4 m/s²) M084GNS1 inverter, M084GNS1 power supply, M084GNS1 electronic board, M084GNS1 VGA board, M084GNS1 touchscreen available.
