NEC NL10276BC24-21BD LCD Display

Panel Brand NEC

Panel Model NL10276BC24-21BD

Panel Size 12.1"

Panel Type a-Si TFT-LCD, LCM

Resolution 1024(RGB)×768, XGA, 105PPI

Pixel Format RGB Vertical Stripe

Display Area 245.76(W)×184.32(H) mm

Bezel Opening 249.0(W)×187.5(H) mm

Outline Size 260.5(W)×203(H) ×11(D) mm

Surface Antiglare, Hard coating (2H)

Brightness 400 cd/m² (Typ.)Contrast Ratio-

Viewing Angle 80/80/80/80 (Typ.)(CR≥10) Left / Right / Up / Down

Display Mode TN, Normally White, Transmissive

Best View on 6 o'clock

Response Time 3/15 (Typ.)(Tr/Td)

Display Colors 262K/16.7M   40% NTSC

Lamp Type 4 strings WLED , 70K hours , Optional

Frequency 60Hz

120Hz (60HZ Input) : Embedded MEMC Circuit

120Hz+120Hz : 120Hz Panel+120Hz Backlight

240Hz (60HZ Input) : Embedded MEMC Circuit

Touch Screen PCAP, Air Bonding

Panel Weight TBD

Application Industrial

Signal Interface LVDS (1 ch, 6/8-bit) , 20 pins Connector

Input Voltage 3.3V (Typ.)

Environment Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C ; Vibration Level: 2.0G (19.6 m/s²)
