NEC NL128102AC28-01 LCD Display

Brand NEC

Model NL128102AC28-01A

Diagonal Size 18.1 inch

Type a-Si TFT-LCD , LCM

Pixel Format 1280(RGB)×1024  [SXGA]  90PPI

Configuration RGB Vertical Stripe

Active Area 359.04(H)×287.232(V) mm

Outline Dim. 424(H)×337(V) mm

Bezel Area 364.0(H)×292.2(V) mm

Luminance 200 cd/m² (Typ.)

Contrast Ratio 150:1 (Typ.) (TM)

View Direction Symmetry

Response Time 45/30 (Typ.)(Tr/Td)

Viewing Angle 85/85/85/85 (Typ.)(CR≥10) Left / Right / Up / Down

Operating Mode SFT, Normally Black, Transmissive

Support Color Full color   60% NTSC

Light Source CCFL  [8 pcs] , With Inverter

Weight 2.28/2.40Kgs (Typ./Max.)

Designed For Desktop Monitor

Frame Rate 60Hz

120Hz (60HZ Input) : Embedded MEMC Circuit

120Hz+120Hz : 120Hz Panel+120Hz Backlight

240Hz (60HZ Input) : Embedded MEMC Circuit

Touch Panel Without

Interface Type Analog RGB , 43 pins Connector

Power Supply 12.0V (Typ.)

Environment Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C

NL128102AC28-01 inverter, NL128102AC28-01 power supply, NL128102AC28-01 electronic board, NL128102AC28-01 VGA board, NL128102AC28-01 touchscreen available.
