Brand NEC
Model NL128102BC28-01
Diagonal Size 18.1 inch
Type a-Si TFT-LCD LCM
Pixel Format 1280(RGB)×1024 [SXGA] 90PPI
Configuration RGB Vertical Stripe
Active Area 359.04(H)×287.232(V) mm
Outline Dim. 383(H)×310.2(V) mm
Bezel Area 366.0(H)×294.2(V) mm
Treatment Hard coating (2H)
Luminance 240 cd/m² (Typ.)
Contrast Ratio 350:1 (Typ.) (TM)
View Direction Symmetry
Response Time 17/16 (Typ.)(Tr/Td)
Viewing Angle 85/85/85/85 (Typ.)(CR≥10) Left / Right / Up / Down
Operating Mode Normally Black, Transmissive
Support Color 16.7M 60% NTSC
Light Source CCFL [6 pcs] , W/O Driver
Weight 2.94/3.10Kgs (Typ./Max.)
Designed For Desktop Monitor Industrial
Frame Rate 60Hz
120Hz (60HZ Input) : Embedded MEMC Circuit
120Hz+120Hz : 120Hz Panel+120Hz Backlight
240Hz (60HZ Input) : Embedded MEMC Circuit
Touch Panel Without
Interface Type LVDS (2 ch, 8-bit) , 60 pins Connector
Power Supply 12.0V (Typ.)
Environment Operating Temperature: 0 ~ 55 °C ; Storage Temperature: -20 ~ 65 °C
