- Brand: NEC
- Model: P/N NL12880BC20-05BD
- Diagonal Size: 12.1 inches.
- Panel Type: Amorphous Silicon (a-Si) Thin-Film Transistor Liquid Crystal Display (TFT-LCD).
- Resolution: 1280 x 800 pixels, providing a pixel density of 124 pixels per inch (PPI).
- Pixel Format: RGB Vertical Stripe.
- Active Area: The display's active area measures 261.12 mm in width and 163.2 mm in height.
- Bezel Opening: The opening in the frame for the screen is 264.1 mm in width and 166.2 mm in height.
- Outline Dimensions: The physical dimensions of the panel are 277.7 mm in width, 180.6 mm in height, and 11.7 mm in depth.
- Surface: The panel surface features an anti-fingerprint and antiglare treatment, as well as a hard coating with a hardness rating of 2H.
- Luminance: The typical luminance (brightness) of the panel is 400 cd/m² (candelas per square meter).
- Contrast Ratio: The typical contrast ratio is 1000:1.
- Viewing Angle: The typical viewing angles are 88 degrees in all directions (left, right, up, and down) when the contrast ratio is greater than or equal to 10.
- Display Mode: This panel is of the UA-SFT (Ultra Advanced Super Fine TFT) type and is normally black and transmissive.
- Best View On: The panel is optimized for symmetry, indicating a consistent viewing experience from different angles.
- Response Time: The typical response time is 25 ms (milliseconds), which is the combined time for both rise (Tr) and fall (Tf) transitions.
- Color Depth: The panel supports 262,000 colors (262K) and has an extended color depth of 16.7 million colors (16.7M). It covers 40% of the NTSC color gamut.
- Backlight: The panel is equipped with a backlight consisting of 4 strings of WLEDs (White Light Emitting Diodes). It has a rated lifespan of 70,000 hours and is optional.
- Frequency: The standard refresh rate for this panel is 60Hz. It also supports higher refresh rates with MEMC (Motion Estimation, Motion Compensation) circuitry.
- Touch Screen: This panel features a touchscreen with PCAP (Projected Capacitive) technology and supports Air Bonding.
- Panel Weight: The weight of the panel ranges from 620 grams (typical) to 680 grams (maximum).
- Application: It is designed for industrial use.
- Signal Interface: It uses LVDS (Low Voltage Differential Signaling) with a 1-channel configuration, and it connects via a 20-pin connector.
- Input Voltage: The typical input voltage for this panel is 3.3V.
- Environment: The panel is designed to operate in a temperature range from -20 to 70°C, with a storage temperature from -30 to 80°C, and it is rated to withstand a vibration level of 2.0G (19.6 m/s²).
