NEC NL6448BC26-09D LCD Display

Panel Brand NEC

Panel Model NL6448BC26-09D

Panel Size 8.4 inch Panel

Type a-Si TFT-LCD , LCM

Resolution 640(RGB)×480, VGA, 95PPI

Pixel Format RGB Vertical Stripe

Display Area 170.88(W)×128.16(H) mm

Bezel Opening 174.0(W)×131.4(H) mm

Outline Size 200(W)×152(H) mm

Surface Antiglare, Hard coating (3H)

Brightness 450 cd/m² (Typ.)

Contrast Ratio 600:1 (Typ.) (TM)

Viewing Angle 80/80/80/60 (Typ.)(CR≥10)

Display Mode TN, Normally White, Transmissive

Best View on 6 o'clock

Response Time 6/19 (Typ.)(Tr/Td)

Display Colors 262K   40% NTSC

Lamp Type 2 pcs CCFL , Without Driver

Frequency 60Hz

Touch Screen Without

Weight330/350g (Typ./Max.)Application

Signal InterfaceCMOS (1 ch, 6-bit) , 31 pins Connector

Input Voltage3.3/5.0V (Typ.)(VCC)

EnvironmentOperating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C ; Vibration Level: 2.0G (19.6 m/s²)
