Content last revised on November 4, 2023
Manufacturer NEC
Model Name NL8060BC26-35E
Screen Size 10.4 inch
Screen TypeLCM, a-Si TFT-LCD
Pixel Number 800(RGB)×600 (SVGA) 96PPI
Arrangement RGB Vertical Stripe
Active Area(mm) 211.2 × 158.4 (H×V)
Outline(mm)243 × 185.1 × 11 (H×V×D)
Bezel Area(mm) 215.4 × 161.8 (H×V)
Treatment Clear, Hard coating (3H)
Luminance 400 cd/m² (Typ.)
Contrast Ratio 900 : 1 (Typ.) (TM)
Viewing Angle 80/80/80/80 (Typ.)(CR≥10) Left / Right / Up / Down
Response 3/15 (Typ.)(Tr/Td) ms
Good View at 3 o'clock
Work Mode TN, Normally White, Transmissive
Color Depth 262K/16.7M 40% NTSC
Backlight 3 strings WLED , 70K hours , Optional
Mass 475/500g (Typ./Max.)
Used for Industrial
Refresh Rate 60Hz
120Hz (60HZ Input) : Embedded MEMC Circuit
120Hz+120Hz : 120Hz Panel+120Hz Backlight
240Hz (60HZ Input) : Embedded MEMC Circuit
Touchscreen Without
Signal Type LVDS (1 ch, 6/8-bit) , 20 pins Connector
Voltage Supply 3.3V (Typ.)
Max. Ratings Storage Temp.: -30 ~ 80 °C Operating Temp.: -30 ~ 80 °C ; Vibration Level: 2.0G (19.6 m/s²)
