Content last revised on September 13, 2023
Manufacturer Part Number: SK95D16Pbfree Code: YesPart Life Cycle Code: ActiveIhs Manufacturer: Semikron INTERNATIONALPackage Description: R-XUFM-X16Pin Count: 16Manufacturer Package Code: CASE T7HTS Code: 8541.10.00.80Manufacturer: SemikronRisk Rank: 5.71Additional Feature: UL RECOGNIZEDCase Connection: ISOLATEDConfiguration: BRIDGE, 6 ELEMENTSDiode Element Material: SILICONDiode Type: BRIDGE RECTIFIER DIODEForward Voltage-Max (VF): 1.1 VJESD-30 Code: R-XUFM-X16JESD-609 Code: e2Non-rep Pk Forward Current-Max: 560 ANumber of Elements: 6Number of Phases: 1Number of Terminals: 16Operating Temperature-Max: 150 °COperating Temperature-Min: -40 °COutput Current-Max: 95 APackage Body Material: UNSPECIFIEDPackage Shape: RECTANGULARPackage Style: FLANGE MOUNTPeak Reflow Temperature (Cel): NOT SPECIFIEDQualification Status: Not QualifiedRep Pk Reverse Voltage-Max: 1600 VSubcategory: Bridge Rectifier DiodesSurface Mount: NOTerminal Finish: Tin/Silver (Sn/Ag)Terminal Form: UNSPECIFIEDTerminal Position: UPPERTime Bridge Rectifier Diode, 1 Phase, 95A, 1600V V(RRM), Silicon, CASE T7, 16 PIN
