Semikron SKM50GDL063D

Content last revised on April 22, 2024

SKM50GDL063D

Maximum ratings and characteristics

.Absolute maximum ratings (Tc=25°C unless without specified)

Collector Emitter Voltage V(br)ceo: 1.2kV

Collector Emitter Voltage Vces: 3.2V

DC Collector Current: 73A

No. of Pins: 12

Operating Temperature Max: 150°C

Operating Temperature Min: -55°C

Power Dissipation Pd: -

SVHC: No SVHC (17-Dec-2014)

Transistor Case Style: Module

Transistor Polarity: Six NPN

Semikron SKM50GDL063D IGBT MODULE 1.2KV 73A
