The specifications for the Kyocera display panel you provided:
- Brand: Kyocera
- Model: P/N TCG121XGLPBPNN-AN40
- Diagonal Size: 12.1 inch
- Panel Type: a-Si TFT-LCD, LCM
- Resolution: 1024(RGB)×768, XGA, 105PPI Pixel Format, RGB Vertical Stripe
- Active Area: 245.76(W)×184.32(H) mm
- Bezel Opening: 249.0(W)×187.5(H) mm
- Outline Dimensions: 260.5(H)×203(V)×10.9(D) mm
- Treatment: Antiglare
- Luminance: 1200 cd/m² (Typ.)
- Contrast Ratio: 750:1 (Typ.) (TM)
- View Direction: Symmetry
- Response Time: 18/12 (Typ.)(Tr/Td)
- Viewing Angle: 85/85/85/85 (Typ.)(CR≥10) Left/Right/Up/Down
- Operating Mode: AWV, Normally Black, Transmissive
- Support Color: 262K/16.2M, 51% NTSC
- Light Source: WLED, 70K hours, With LED Driver
- Weight: 555g
- Designed For: Industrial Outdoor High Brightness
- Frame Rate: 60Hz, 120Hz (60HZ Input) with Embedded MEMC Circuit, 120Hz+120Hz (120Hz Panel+120Hz Backlight), 240Hz (60HZ Input) with Embedded MEMC Circuit
- Touch Panel: Without
- Interface Type: LVDS (1 ch, 6/8-bit), 20 pins Connector
- Power Supply: 3.3V (Typ.)
- Environment: Operating Temperature: -30 ~ 80 °C, Storage Temperature: -30 ~ 80 °C
