- Diagonal Size: 7.0 inches
- Panel Type: a-Si TFT-LCD (Amorphous Silicon Thin-Film Transistor Liquid Crystal Display)
- Resolution: 800 (RGB) × 480 pixels, WVGA
- Pixel Format: RGB Vertical Stripe
- Active Area: 154.08 (W) × 85.92 (H) mm
- Bezel Opening: 157.08 (W) × 90.1 (H) mm
- Outline Dimensions: 164.9 (H) × 100 (V) × 6 (D) mm
- Treatment: Antiglare
- Luminance: 350 cd/m² (Typical)
- Contrast Ratio: 500:1 (Typical)
- Viewing Angle: 70°/70°/60°/70° (Typical) - Left/Right/Up/Down
- Response Time: 20 ms (Typical) (Tr+Td)
- Work Mode: TN (Twisted Nematic), Normally White, Transmissive
- Color Depth: 262K/16.7M (50% NTSC)
- Backlight: 3S7P WLED (White Light Emitting Diode), 20,000 hours lifespan, No Driver
- Mass: To Be Determined (TBD)
- Used for: Automotive Display, Digital Photo Frame, Portable DVD Player
- Refresh Rate: 60Hz (Panelook copyright, copy is strictly prohibited), 120Hz (60Hz Input) with Embedded MEMC Circuit, 120Hz+120Hz (120Hz Panel + 120Hz Backlight), 240Hz (60Hz Input) with Embedded MEMC Circuit
- Touchscreen: Without
- Signal Type: Parallel RGB (1 channel, 6/8-bit), FPC (Flexible Printed Circuit) with 60 pins
- Voltage Supply: 3.3V (VCC), 10.6V (AVDD), 16.0V (VGH), -7.0V (VGL) (Typical)
- Max. Ratings: Storage Temperature: -30 ~ 80°C, Operating Temperature: -20 ~ 70°C
