Content last revised on September 18, 2023
- Diagonal Size: 7.0 inches
- This is the size of the display panel measured diagonally.
- Panel Type: a-Si TFT-LCD, LCM
- The display panel is of the a-Si (amorphous silicon) Thin-Film Transistor Liquid Crystal Display (TFT-LCD) type.
- Resolution: 800(RGB)×480, WVGA
- The panel has a resolution of 800 pixels in the horizontal (RGB) direction and 480 pixels in the vertical direction, making it a WVGA display.
- Pixel Format: RGB Vertical Stripe
- The arrangement of the pixels on the panel is in an RGB vertical stripe format.
- Active Area: 154.08(W)×85.92(H) mm
- This is the dimension of the screen's active area where images are displayed.
- Bezel Opening: 157.08(W)×89.39(H) mm
- The bezel opening represents the area of the frame around the active display area.
- Outline Dimensions: 164.9(H)×100(V)×6(D) mm
- These are the physical dimensions of the entire display panel.
- Treatment: Antiglare
- The display panel has an antiglare treatment to reduce reflections.
- Luminance: 1000 cd/m² (Typ.)
- The typical brightness of the display is 1000 nits (candelas per square meter), indicating high brightness suitable for outdoor use.
- Contrast Ratio: 800:1 (Typ.)
- The typical contrast ratio of the display is 800:1.
- Viewing Angle: 70/70/60/70 (Typ.)(CR≥10) Left / Right / Up / Down
- The typical viewing angles for the display are 70 degrees to the left, 70 degrees to the right, 60 degrees up, and 70 degrees down, with a contrast ratio of at least 10.
- Response Time: 25 (Typ.)(Tr+Td) ms
- The typical response time of the display is 25 milliseconds (milliseconds) for both rise and fall times.
- Good View at: 6 o'clock
- The optimal viewing direction for this display is at 6 o'clock.
- Work Mode: TN, Normally White, Transmissive
- The display panel uses a Twisted Nematic (TN) technology, is normally white in its unpowered state, and is transmissive.
- Color Depth: 16.7M (50% NTSC)
- The display supports 16.7 million colors and covers approximately 50% of the NTSC color gamut.
- Backlight: 3S8P WLED , 50K hours , No Driver
- The panel uses a White Light Emitting Diode (WLED) backlight with a rated lifetime of 50,000 hours. It does not require an external LED driver.
- Mass: To Be Determined (TBD)
- The exact mass or weight of the display is not specified.
- Used for: Industrial Outdoor High Brightness Automotive Display
- The display panel is designed for use in industrial applications, outdoor environments, high-brightness settings, and automotive displays.
- Refresh Rate: 60Hz
- The panel has a standard frame rate of 60Hz.
- Touchscreen: Without
- The display does not include a touchscreen.
- Signal Type: Parallel RGB (1 ch, 8-bit) , FPC 50 pins
- The display panel uses a parallel RGB interface with 1 channel and 8-bit data, and it connects via a 50-pin Flexible Printed Circuit (FPC) connector.
- Voltage Supply: 3.3/10.4/16.0/-7.0V (Typ.)(VCC/AVDD/VGH/VGL)
- The typical input voltage requirements for various power supplies are provided.
- Max. Ratings:
- Storage Temperature: -40 ~ 90 °C
- Operating Temperature: -30 ~ 85 °C
- Vibration Level: 6.8G (66.64 m/s²)
