Content last revised on September 18, 2023
Diagonal Size: 7.0 inches
Panel Type: a-Si TFT-LCD, LCM (Liquid Crystal Module)
Resolution: 800 (RGB) × 480 pixels, WVGA, with a pixel format of RGB Vertical Stripe
Active Area: 157.2(W) × 82.32(H) mm
Bezel Opening: Not specified
Luminance: Not specified
Viewing Angle: 70/70/60/70 degrees (Typical, CR≥10) for Left/Right/Up/Down
Good View at: Not specified
Color Depth: 262,000 colors (262K)
Mass: Not specified
Refresh Rate: Not specified
-
- 60Hz (Panel refresh rate)
- 120Hz (with embedded MEMC circuit, 60Hz input)
- 120Hz+120Hz (120Hz Panel + 120Hz Backlight)
- 240Hz (with embedded MEMC circuit, 60Hz input)
Contrast Ratio: 400:1 (Typical)
Work Mode: TN (Twisted Nematic), Normally White, Transmissive
Response Time: 20 milliseconds (Typical, Tr+Td)
Backlight: WLED (White LED)
Used for: Automotive Display
Touchscreen: PCAP (Projected Capacitive Touch)
Max. Ratings:
-
- Storage Temperature: -40 ~ 90 °C
- Operating Temperature: -30 ~ 80 °C
