The BOE display model P/N TV101WUM-NL1:
- Diagonal Size: 10.1 inches.
- Panel Type: a-Si TFT-LCD, LCM (Liquid Crystal Module).
- Resolution: 1200 (RGB) × 1920 pixels, which is WUXGA. The pixel format is RGB Vertical Stripe.
- Active Area: 135.36 mm in width and 216.576 mm in height.
- Outline Dimensions: The display module's overall dimensions are 142.96 mm in width, 227.926 mm in height, and 3.8 mm in depth.
- Treatment: The display features an anti-fingerprint and clear treatment, along with a hard coating.
- Luminance: The typical brightness is 400 cd/m² (candela per square meter).
- Contrast Ratio: The typical contrast ratio is 1000:1 (TM) (Transmissive Mode).
- View Direction: The display is optimized for symmetry.
- Response Time: The typical response time is 30 ms, which is the sum of the rise time (Tr) and the fall time (Td).
- Viewing Angle: 85/85/85/85 (Typ.)(CR≥10).
- Operating Mode: The display operates in HADS (High Amplitude Driving Scheme) and is normally black and transmissive.
- Support Color: It supports 16.7 million colors and covers 98% of the sRGB color space.
- Light Source: The display uses a WLED (White LED) backlight with an 8S4P configuration and has a lifespan of 15,000 hours. It does not require a separate driver.
- Weight: The typical weight of the panel is 105 grams.
- Designed For: This display is designed for use in pad and tablet devices.
- Frame Rate: The native refresh rate of the panel is 60Hz.
- Touch Panel: This particular model does not have a touch panel.
- Interface Type: The panel uses a MIPI (Mobile Industry Processor Interface) interface with 4 data lanes and a 45-pin connector.
- Power Supply: The typical input voltage is 3.3V.
- Operating Environment: The operating temperature range is -20°C to 60°C, and the storage temperature range is -30°C to 70°C.
