Content last revised on September 18, 2023
Diagonal Size: 7.0 inches
Panel Type: a-Si TFT-LCD, LCM
Resolution: 800(RGB)×480 pixels (WVGA)
Pixel Format: RGB Vertical Stripe
Active Area: 152.4(W)×91.44(H) mm
Bezel Opening: 155.74(W)×94.74(H) mm
Outline Dimensions: 166.1 × 107.8 × 14.9 mm (H×V×D)
Treatment: Antiglare
Luminance: 360 cd/m² (Typical)
Contrast Ratio: 600 : 1 (Typical) (TM)
Viewing Angle: 85/85/85/85 (Typical) (CR≥10) - Left / Right / Up / Down
Response Time: 45 ms (Max.) (Tr+Td)
Good View at: Symmetry
Work Mode: IPS (In-Plane Switching), Normally Black, Transmissive
Color Depth: 262K (51% NTSC coverage)
Backlight: 3S4P WLED (White Light Emitting Diodes), rated for 70,000 hours of usage with LED Driver
Mass: 300g (Typical)
Used for: Industrial applications
Refresh Rate: 60Hz; also supports higher refresh rates with certain configurations (e.g., 120Hz, 240Hz)
Touchscreen: 4-wire Resistive Touch, F/G (Film/Film-Glass)
Signal Type: CMOS (1 channel, 6-bit), 40 pins Connector
Voltage Supply: 3.3V (Typical)
Max. Ratings:
Storage Temperature: -30 to 80 °C
Operating Temperature: -20 to 70 °C
Vibration Level: 3.0G (29.4 m/s²)
