Content last revised on September 12, 2023
Manufacturer Part Number: W0503SC160Part Life Cycle Code: ActiveIhs Manufacturer: WESTCODE SEMICONDUCTORS LTDPackage Description: O-MUPM-H1ECCN Code: EAR99HTS Code: 8541.10.00.80Manufacturer: IXYS UK WestcodeRisk Rank: 5.69Application: GENERAL PURPOSECase Connection: CATHODEConfiguration: SINGLEDiode Element Material: SILICONDiode Type: RECTIFIER DIODEForward Voltage-Max (VF): 1.88 VJESD-30 Code: O-MUPM-H1Non-rep Pk Forward Current-Max: 6050 ANumber of Elements: 1Number of Phases: 1Number of Terminals: 1Operating Temperature-Max: 180 °COperating Temperature-Min: -30 °COutput Current-Max: 503 APackage Body Material: METALPackage Shape: ROUNDPackage Style: POST/STUD MOUNTQualification Status: Not QualifiedRep Pk Reverse Voltage-Max: 1600 VReverse Current-Max: 15000 µASurface Mount: NOTerminal Form: HIGH CURRENT CABLETerminal Position: UPPER DIODE 370 A, 1600 V, SILICON, RECTIFIER DIODE, Rectifier Diode
