Content last revised on July 12, 2023
Manufacturer Part Number: ZXTPS720MCTAPbfree Code: YesPart Life Cycle Code: ActiveIhs Manufacturer: DIODES INCPart Package Code: DFNPackage Description: SMALL OUTLINE, R-XDSO-N8Pin Count: 3Manufacturer Package Code: CASE DFN3020B-8ECCN Code: EAR99Manufacturer: Diodes IncorporatedRisk Rank: 1.82Collector Current-Max (IC): 3 ACollector-Emitter Voltage-Max: 40 VConfiguration: SINGLE WITH BUILT-IN DIODEDC Current Gain-Min (hFE): 12JESD-30 Code: R-XDSO-N8JESD-609 Code: e4Moisture Sensitivity Level: 1Number of Elements: 1Number of Terminals: 8Operating Temperature-Max: 150 °CPackage Body Material: UNSPECIFIEDPackage Shape: RECTANGULARPackage Style: SMALL OUTLINEPeak Reflow Temperature (Cel): 260Polarity/Channel Type: PNPPower Dissipation-Max (Abs): 3 WQualification Status: Not QualifiedSubcategory: Other TransistorsSurface Mount: YESTerminal Finish: Nickel/Palladium/Gold (Ni/Pd/Au)Terminal Form: NO LEADTerminal Position: DUALTime Small Signal Bipolar Transistor, 3A I(C), 40V V(BR)CEO, 1-Element, PNP, Silicon, GREEN, CASE DFN3020B-8
