Content last revised on November 4, 2024
Manufacturer OPTREX
Model Name DMF-50036ZNB-FW
Screen Size 9.6 inch
Screen Type LCM , STN-LCD
Pixel Number 640×200 69PPI
Arrangement Rectangle
Active Area(mm) 223.97 × 97.97 (H×V)
Outline(mm) 270 × 142 (H×V×D)
Bezel Area(mm) 231.0 × 105.0 (H×V)
Contrast Ratio 5 : 1 (Typ.) (TM)
Response 150/350 (Typ.)(Tr/Td) ms
Work Mode STN
Color Depth Monochrome Backlight CCFL
Used for Industrial
Refresh Rate 70Hz
120Hz (60HZ Input) : Embedded MEMC Circuit
120Hz+120Hz : 120Hz Panel+120Hz Backlight
240Hz (60HZ Input) : Embedded MEMC Circuit
Signal Type Parallel Data (4-bit) , 12 pins
Voltage Supply 5.0V (Typ.)
Max. Ratings Storage Temp.: -20 ~ 60 °C Operating Temp.: 10 ~ 40 °C
