LG LP150X09-B5K2 LCD Display

Brand LG.Philips LCD
Model P/N LP150X09-B5K2
Diagonal Size 15.0 inch
Panel Type a-Si TFT-LCD, LCM
Resolution 1024(RGB)×768, XGA 85PPI
Pixel Format RGB Vertical Stripe
Active Area 304.128(W)×228.096(H) mm
Bezel Opening 307.5(W)×231.4(H) mm
Outline (mm) 317.3×241.5×6 (H×V×D)
Treatment Antiglare, Hard coating (3H)
Luminance 180 cd/m² (Typ.)
Contrast Ratio 350 : 1 (Min.) (TM)
Viewing Angle 45/45/15/35 (Typ.)(CR≥10) Left / Right / Up / Down
Response 30 (Typ.)(Tr+Td) ms
Good View at 6 o'clock
Work Mode TN, Normally White, Transmissive
Color Depth 262K 45% NTSC
Backlight 1 pcs CCFL , 15K hours , With Inverter
Outline Shape Wedge (PCBA Bent, T≥5.2mm)
Used for Laptop
Refresh Rate 60Hz
120Hz (60HZ Input) : Embedded MEMC Circuit
120Hz+120Hz : 120Hz Panel+120Hz Backlight
240Hz (60HZ Input) : Embedded MEMC Circuit
Touchscreen Without
Signal Type LVDS (1 ch, 6-bit) , Connector 30 pins
Voltage Supply 3.3V (Typ.)
Max. Ratings Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C
