Samsung LTM150X0-L01 15" XGA Display | Reliable Industrial LCD
Technical Introduction to the LTM150X0-L01 a-Si TFT-LCD
The Samsung LTM150X0-L01 is a 15.0-inch TFT-LCD module designed for consistent performance in commercial and light-industrial systems. Its core is built on amorphous Silicon (a-Si) thin-film transistor technology, providing a stable and proven platform for visual interfaces. Key specifications include a 1024x768 XGA resolution, a 250 cd/m² typical brightness, and a 1-channel, 6-bit LVDS interface. This display's construction prioritizes durability, featuring a robust anti-glare surface and a hard coating. For engineers evaluating displays for environments with controlled lighting and potential surface interaction, the LTM150X0-L01's protective surface treatment is a critical design feature that enhances both readability and service life.
Proven Integration in Commercial and Industrial Systems
The LTM150X0-L01 has a track record of deployment in systems where long-term operational stability is a primary consideration. Its standard mechanical footprint and common LVDS interface have made it a candidate for integration into a variety of equipment. What is the panel's surface treatment? An anti-glare coating with 3H hardness for durability and readability, a key factor in its successful use in high-traffic commercial environments.
- Point-of-Sale (POS) Terminals: The panel's dimensions and surface durability are well-suited for retail and hospitality checkout systems.
- Industrial HMI Panels: Used in factory automation control panels where a clear, reliable display is necessary for machine operation and monitoring.
- Medical Diagnostic Equipment: Integrated into non-critical patient monitoring and instrumentation displays that require consistent image reproduction.
LTM150X0-L01 Specification Cross-Reference
For system architects and engineers, evaluating component specifications is a critical step. The following provides a factual comparison to support your decision-making process. The data presented is for informational purposes, allowing for a direct assessment of key performance indicators based on documented specifications. For applications requiring different resolutions or advanced features, other panels like the G150XNE-L01 may offer alternative specifications for consideration.
| Parameter | Samsung LTM150X0-L01 | Alternative Category (Typical) |
|---|---|---|
| Screen Size | 15.0 inch | 15.0 inch |
| Resolution | 1024x768 (XGA) | 1024x768 (XGA) or Higher |
| Backlight | 2 pcs CCFL | LED |
| Surface Treatment | Anti-Glare, Hard coating (3H) | Varies (Glossy, Anti-Glare) |
| Operating Temperature | 0 ~ 50 °C | Wider ranges available (e.g., -20 ~ 70 °C) |
The Strategic Value of Durability in Display Technology
In the realm of industrial and commercial electronics, the total cost of ownership often outweighs the initial component cost. The design choices within the LTM150X0-L01 reflect an understanding of this principle. While modern displays may offer higher brightness or wider color gamuts, the emphasis on mechanical resilience—evidenced by its 3H hard-coated surface—provides a tangible advantage. This protective layer mitigates the risk of scratches and minor impacts that are common in interactive kiosk, POS, and HMI applications. This focus on physical durability contributes directly to a longer operational life and reduced need for field replacements, aligning with strategies that prioritize system uptime and lower long-term maintenance overhead. For a broader understanding of this topic, see our guide on Industrial vs. Consumer Displays.
LTM150X0-L01 Core Technical Specifications: An Engineering-Focused Breakdown
The following parameters are sourced from the official product datasheet. This data provides the foundation for system integration and performance evaluation. For complete details, please refer to the official manufacturer's documentation.
| Display Characteristics | |
|---|---|
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 1024(RGB)×768, XGA |
| Active Area | 304.128(H) × 228.096(V) mm |
| Brightness | 250 cd/m² (Typ.) |
| Contrast Ratio | 300:1 (Typ.) (TM) |
| Viewing Angle | 60/60/50/40 (Typ.)(CR≥10) |
| Display Colors | 262K (6-bit) |
| Response Time | 10/25 (Typ.)(Tr/Td) ms |
| Interface & Electrical | |
|---|---|
| Signal Interface | LVDS (1 ch, 6-bit), 20 pins Connector |
| Input Voltage | 3.3V (Typ.) |
| Backlight System | 2 pcs CCFL with 50K hour typical life |
| Mechanical & Environmental | |
|---|---|
| Outline Dimensions | 326.5(W) × 253.5(H) × 12(D) mm |
| Surface Treatment | Anti-Glare (Haze 25%), Hard coating (3H) |
| Operating Temperature | 0 to 50 °C |
| Storage Temperature | -20 to 60 °C |
Target Applications for the LTM150X0-L01: Where Reliability Intersects Functionality
The specific feature set of the Samsung LTM150X0-L01 makes it a suitable choice for a defined range of applications where its particular strengths provide maximum value. The display's performance is not about pushing the boundaries of resolution or color, but about delivering dependable visual output in environments that are more demanding than a standard office. For legacy industrial HMI systems requiring a 15-inch XGA panel with proven LVDS-1ch interfacing, the LTM150X0-L01 presents a mechanically sound and electrically compatible solution.
Interpreting Key Parameters for Application Fit
- Surface Treatment (Anti-Glare, 3H Hard Coating): The anti-glare surface acts like a noise-canceling filter for light, diffusing strong ambient reflections so the intended image comes through clearly. The 3H hardness rating provides a significant level of protection against incidental contact, crucial for touch-interface overlays or public-facing kiosks.
- CCFL Backlight: The dual Cold Cathode Fluorescent Lamp system is a mature technology known for its stable output over its lifespan. With a typical life of 50,000 hours, it provides a predictable maintenance schedule for systems intended for long-term deployment. This is a key data point for calculating service intervals and ensuring system uptime.
In-Depth Analysis of Display Construction and Interface
The LTM150X0-L01 is an example of established TFT-LCD technology. Its normally white, transmissive mode operation is standard for the technology class, ensuring that pixel failure results in a white dot, which is often less intrusive in industrial graphics than a black one. What is the native resolution of this display? The LTM150X0-L01 provides a standard 1024x768 XGA resolution, which remains a common requirement for legacy software and systems where upgrading the entire graphical interface is not feasible. The single-channel LVDS interface further simplifies integration into existing controller boards that were designed around this widespread standard. For more foundational knowledge, explore our guide to TFT LCDs.
Frequently Asked Questions (FAQ)
1. What are the key details of the LTM150X0-L01's CCFL backlight system for maintenance purposes?
The LTM150X0-L01 uses a two-lamp CCFL backlight system. Key considerations for maintenance include its typical lifespan of 50,000 hours, after which brightness will degrade significantly. It also requires an external high-voltage inverter to operate, which should be considered as part of the power and maintenance budget. The lamps are located at the top and bottom edges of the panel.
2. Is the 1-channel LVDS interface on the LTM150X0-L01 compatible with modern 2-channel systems?
No, not directly. The LTM150X0-L01 is designed for a 1-channel, 6-bit LVDS signal. While a modern controller might support dual-channel outputs, it would need to be specifically configured to output a single-channel signal compatible with this display's 20-pin connector and data mapping. Direct connection of a 2-channel signal will not work and could potentially damage the display's timing controller.
Request for Quotation and Technical Support
To evaluate the LTM150X0-L01 for your application, please contact our technical sales team. We can provide additional information and data to support your engineering and procurement processes. Please have your project requirements ready to facilitate a detailed discussion.
```
