The BOE display model P/NTV101WUM-NH0:
- Diagonal Size: 10.1 inches.
- Panel Type: a-Si TFT-LCD, LCM (Liquid Crystal Module).
- Resolution: 1200 (RGB) × 1920 pixels, which is WUXGA. The pixel format is RGB Vertical Stripe.
- Active Area: 135.36 mm in width and 216.576 mm in height.
- Outline Dimensions: The display module's overall dimensions are 143 mm in width and 227.93 mm in height.
- Surface: The surface treatment is not specified in the provided information.
- Brightness: The typical brightness is 400 cd/m² (candela per square meter).
- Contrast Ratio: The typical contrast ratio is 900:1 (TM) (Transmissive Mode).
- Viewing Angle: The typical viewing angles are 80 degrees left, 80 degrees right, 80 degrees up, and 80 degrees down, with a contrast ratio of at least 10.
- Display Mode: The display operates in ADS (Advanced Super Dimension Switch) technology and is normally black and transmissive. It is also part of the IPS (In-Plane Switching) family, which includes various IPS subtypes like AAS, ADS, AHVA, FFS, HIS, IPS, New Mode2, PLS, SFT, and Vistarich, as well as the VA (Vertical Alignment) family with subtypes like ASV, FSA, HVA, MVA, PVA, SVA, UV²A, and VA.
- Best View on: The display is optimized for symmetry.
- Response Time: The typical response time is 25 ms (Tr+Tf).
- Display Colors: It supports 16.7 million colors and covers 100% of the sRGB color space.
- Lamp Type: The display uses an 8S4P WLED (White LED) backlight and does not require a separate driver.
- Frequency: The native refresh rate of the panel is 60Hz.
- Touch Screen: This particular model does not have a touch screen.
- Panel Weight: The maximum weight of the panel is 130 grams.
- Application: It is designed for use in pad and tablet devices.
- Signal Interface: The panel uses a MIPI (Mobile Industry Processor Interface) interface with 4 data lanes and a 39-pin connector.
- Input Voltage: The typical input voltage ranges are 3.3V (VDD) and 3.8V (VBAT).
- Operating Environment: The operating temperature range is -10°C to 60°C, and the storage temperature range is -30°C to 70°C.
