Microsemi SM16Z4689 IGBT Module

SM16Z4689 IGBT Module | Redefining Efficiency in High-Density Power Conversion

The SM16Z4689 is not just another power component; it's a highly integrated power conversion engine engineered for the next generation of demanding industrial applications. Designed for superior thermal performance and minimal switching losses, this module empowers designers to build more compact, reliable, and energy-efficient motor drives, uninterruptible power supplies (UPS), and renewable energy systems. By integrating a high-performance three-phase inverter stage, the SM16Z4689 simplifies system layout, reduces parasitic inductance, and accelerates your time-to-market.

Technical Deep Dive: The Core of Performance

The standout performance of the SM16Z4689 stems from its advanced internal architecture, which directly addresses the core challenges of modern power electronics: efficiency and reliability.

• Advanced Trench Field-Stop (TFS) Technology: This module leverages state-of-the-art Trench Field-Stop technology, which fundamentally re-engineers the carrier profile within the silicon. The result is a dramatically lower collector-emitter saturation voltage (Vce(sat)) and a significantly reduced tail current during turn-off. For your application, this translates directly to lower conduction and switching losses, leading to higher overall inverter efficiency and a reduced need for bulky, expensive heatsinking.
• Optimized Soft-Recovery Freewheeling Diodes: Paired with the TFS IGBTs are co-packaged, soft-recovery freewheeling diodes (FWDs). These diodes exhibit an exceptionally low forward voltage drop and controlled reverse recovery characteristics. This synergy minimizes voltage overshoots and high-frequency oscillations (EMI), simplifying the design of snubber circuits and EMC filters. The low IGBT Vce(sat) ensures minimal power dissipation when the device is on, a critical factor for systems operating under heavy loads.

Application-Specific Value: Where the SM16Z4689 Excels

Simply listing applications is not enough. Here’s how the SM16Z4689 provides tangible benefits in specific industrial scenarios:

• Motor Drives & Servo Control: In variable frequency drives (VFDs), the module's low losses and high switching frequency capability enable smoother torque control and reduced acoustic motor noise. Its robust thermal efficiency ensures stable operation even during demanding overload conditions, ultimately extending both motor and drive lifespan.
• Uninterruptible Power Supplies (UPS): For online double-conversion UPS systems, every percentage point of efficiency matters. The SM16Z4689 minimizes energy waste in the inverter stage, which reduces long-term operating costs and maximizes battery runtime during critical power outages.
• Welding Equipment: The fast, clean switching of the SM16Z4689 allows for precise control over the welding arc in advanced inverter-based welding machines. This results in higher-quality, more consistent welds, less material spatter, and the ability to design more portable and robust equipment.

Key Technical Parameters at a Glance

For complete specifications, please refer to the SM16Z4689 Datasheet.

Selection Guidance: SM16Z4689 vs. Conventional CIB Modules

Engineers often weigh the SM16Z4689 against standard Converter-Inverter-Brake (CIB) modules. While a CIB module offers a convenient all-in-one solution for simple motor drives, the SM16Z4689 provides a more specialized three-phase inverter stage with superior switching characteristics and thermal performance. Choose the SM16Z4689 when your primary goal is maximizing inverter efficiency, achieving higher PWM frequencies, or when designing a system with a separate or more complex front-end, such as an active front end (AFE). For a broader selection of power solutions, you can explore more IGBT modules in our catalog.

Frequently Asked Questions

• What is the recommended gate drive voltage for the SM16Z4689?
  For optimal performance and to ensure full saturation while maintaining reliability, a gate voltage of +15V for turn-on and -8V to -15V for turn-off is recommended. This provides excellent immunity against dv/dt induced turn-on.
• Can this IGBT module be paralleled for higher current applications?
  Yes, the SM16Z4689 is designed with tight parameter distribution and a positive temperature coefficient for Vce(sat), which facilitates stable current sharing. However, careful PCB layout to ensure symmetrical gate drive paths and minimal stray inductance is critical for successful paralleling.
• What is the purpose of the integrated NTC thermistor?
  The built-in NTC thermistor allows for real-time monitoring of the module's baseplate temperature. This data is crucial for implementing over-temperature protection in the drive's control logic, preventing thermal runaway and enhancing overall system reliability.

To discuss your specific application requirements or to obtain a sample, please contact us for a quote and our technical team will be happy to assist you.
